How to Size Your LED Driver for COB Strip Lighting (Singapore Guide)

That LED strip looked perfect on paper - until it dimmed unevenly, flickered, or failed early because the driver was undersized. If you're figuring out how to size LED driver for a renovation or room upgrade, this is the part that decides whether your lighting feels smooth and reliable or turns into a callback later.

For most home projects, sizing the driver is not complicated. The catch is that you need the right type of driver first, then the right wattage headroom. Get either one wrong and even a good light fitting can perform badly.

How to size LED driver the right way

Start with three numbers: output voltage, total load wattage, and available installation space. Voltage must match exactly. Wattage needs buffer. Space matters because a driver that technically works but does not fit your ceiling void or cabinet run is still the wrong driver.

If you are powering constant voltage LED strips, the process is usually straightforward. Check whether the strip is 12V or 24V, then multiply the strip wattage per meter by the total length. After that, add headroom of about 20% to 30% so the driver is not running flat out all the time.

For example, if your COB strip is 10 watts per meter and you are installing 5 meters, your total load is 50W. A 60W driver may work on paper, but an 80W driver is usually the better choice if you want cooler operation and more stable long-term performance.

For constant current products like some downlights, linear lights, or specialty fixtures, you do not size by strip length. You match the fixture's required output current and voltage range to the driver's output specs. This is where many mismatches happen, because constant voltage and constant current are not interchangeable.

First, know whether you need constant voltage or constant current

This is the decision that comes before wattage.

Constant voltage drivers are commonly used with LED strip lighting. These drivers output a fixed voltage, usually 12V or 24V, and the strip draws the current it needs. If your strip is labeled 24V DC, you need a 24V constant voltage driver. Not 12V, not a wide-range current driver, and not "close enough."

Constant current drivers are used when the fixture itself specifies a drive current such as 350mA, 500mA, 700mA, or 1050mA. In that setup, the driver regulates current and the voltage floats within a specified range. The fixture and driver need to agree on current first, and then the fixture's forward voltage has to sit inside the driver's voltage range.

If you're shopping for residential LED strips, under-cabinet lighting, cove lighting, or tunable white strip setups, you are usually working with constant voltage. If you are replacing an integrated driver for a downlight or architectural fixture, check the label carefully before buying anything.

Calculate the total wattage load

Once the driver type is confirmed, the next step is the load.

For LED strips, use this simple formula:

Total wattage = watts per foot or meter x total length

If your strip is 4.4W per foot and you are using 12 feet, the total load is 52.8W. If your strip is 12W per meter and the run is 3 meters, the load is 36W.

If you have multiple runs on one driver, add all of them together. This is where people often undercount. A kitchen may have one continuous visual line of light, but electrically it may be two or three separate runs fed from the same driver.

For downlights or fixtures using a driver shared across multiple heads, add the wattage of each compatible fixture. If four heads are 8W each, the total is 32W.

Why headroom matters

A driver should not be chosen to match the exact load unless the manufacturer specifically allows it and the installation conditions are favorable. In real homes, heat buildup, enclosed ceiling spaces, and long operating hours all add stress.

A practical target is to load the driver to about 70% to 85% of its rated capacity. That usually means adding 20% to 30% above your calculated load.

If your lights need 48W, a 60W driver is the minimum sensible pick. A 75W or 80W driver may be even better if space allows. The benefit is not just longevity. You are also reducing the chance of nuisance issues like startup instability, thermal shutdown, or dimming behavior that feels inconsistent.

Bigger is not always better, though. Oversizing within reason is fine. Going dramatically oversized can be unnecessary, more expensive, and harder to fit into tight ceiling spaces or cabinetry. The goal is buffer, not excess for its own sake.

Match dimming method, not just wattage

This is the part many homeowners only discover after the false ceiling is closed.

If you want dimming, the driver must support the dimming method your system uses. A non-dimmable driver on a dimming circuit will not become dimmable because the wall control says it should. Likewise, a driver built for one control method may not behave properly on another.

Common setups include standard on-off drivers, TRIAC dimmable drivers, 0-10V dimmable drivers, and smart-compatible low-voltage controllers used with LED strips. Tunable white setups add another layer, because you are not only powering the strip but also managing two color-temperature channels through the correct controller and power supply arrangement.

So when you size the driver, include the control plan in the decision. The correct wattage with the wrong dimming type is still the wrong driver.

Installation conditions affect driver choice

On renovation projects, the paper specs are only half the story. The driver also has to suit the way the lighting is being installed.

If the driver is going inside a tight cove, ceiling recess, or cabinet void, heat management matters more. In that case, giving yourself extra wattage headroom is smart. So is choosing a reliable driver that can maintain stable output over time instead of the cheapest unit with a matching number on the label.

Cable distance matters too. Longer low-voltage runs can create voltage drop, especially on 12V systems. That can lead to visible brightness loss by the end of the strip. In many residential strip installations, 24V is the better choice because it handles longer runs more gracefully and often gives cleaner, more consistent performance.

For compact homes and typical renovation layouts, this is one reason 24V COB strip systems are so popular. You get smoother light, less visible dotting, and better flexibility when the power source cannot sit right next to the lighting run.

Common sizing mistakes

The most common mistake is matching only wattage and ignoring output type. A 60W driver is not automatically suitable just because your strip load is 50W. It still has to be the correct voltage.

The second mistake is forgetting total run length. People often calculate one section and miss the second shelf, the wardrobe return, or the extra cove section in the dining area.

The third is buying with no headroom. A driver operating at its ceiling may work at first, then start showing issues after months of regular use.

Another frequent problem is mixing dimmable and non-dimmable components. If your plan includes smart control, tunable white, or wall dimming, check compatibility before the electrician starts closing things up.

A few real-world examples

A simple bedroom cove uses 4 meters of 24V COB strip at 10W per meter. Total load is 40W. Add 25% headroom and you land at 50W, so a 60W 24V driver is the practical pick.

A longer living room cove uses 8 meters of 24V strip at 12W per meter. Total load is 96W. With headroom, you should be looking at around 120W to 150W depending on enclosure conditions and whether the run will be split across feeds.

A vanity mirror uses 3 meters of 12V strip at 8W per meter. Total load is 24W. A 30W driver might run it, but a 40W 12V driver gives better breathing room.

A downlight replacement requires 700mA constant current with a forward voltage of 24V to 36V. In this case, wattage is not your first filter. You need a constant current driver at 700mA whose voltage range includes that fixture.

When to pause and ask for help

If the fixture label is unclear, the project uses multiple strip zones, or you are combining dimming and tunable white controls, it is worth confirming the setup before purchase. This matters even more when the driver will be hidden behind carpentry or inside a finished ceiling, where replacement is inconvenient.

At The Lighting Gallery, we see this all the time with renovation-phase purchases. The fastest way to get it right is to work from the actual strip or fixture specs, total run length, and control method, then choose a driver with proper headroom and fit. That avoids the false savings of replacing mismatched parts later.

A well-sized driver is one of those details nobody notices when it is done right. They just notice the result - smooth glow, no flicker, accurate color, and lighting that behaves the same on day one and months later.
